PSA hydrogen generator
PSA hydrogen production systems
A PSA hydrogen generator produces high-purity hydrogen by using adsorbent materials (like Carbon Molecular Sieves) in tanks to selectively capture impurities (like nitrogen, CO, CO2, water) from a gas stream under varying pressures, allowing pure hydrogen to pass through for continuous supply, widely used in electronics, chemicals, and fuel cells for its reliability and cost-effectiveness.
Apply Scope
In the pressure swing adsorption process, the desorption of the adsorbent in the adsorber is achieved by reducing the partial pressure of impurities. The methods that can be adopted in industrial equipment include
（1) Reduce the pressure of the adsorber (depressurization)
（2) Evacuate the air from the adsorber
（3) Rinse with the product components
Technical features
1、The purity of H2 can reach 99% to 99.99999% and is easy to adjust.
2、The technology is mature, highly adaptable and has a high degree of automation.
3、The process flow is simple, the operation is flexible, and it is convenient to start and stop.
| Usage | Hydrogen | Production Rate | Customized |
|---|---|---|---|
| Voltage | 380 V | Place Of Origin | Jiangsu,China |
| Weight | 25000 Kg | Warranty | 2 Years |
| Key Selling Points | High-Accuracy | Core Components | Pressure Vessel,Plc,Gear |
| Color | White | Purity | 0.999999 |
| Capacity | Customized | Brand Name | Bangwin |
| Dimension(L*W*H) | Customized | Machinery Test Report | Provided |
| Video Outgoing- Inspection | Provided | Capacity | Customizable |
| Certification | ISO9001 | Technical Features | High Degree Of Automation |
Project
Natural Gas to Hydrogen Production Pilot Unit
Feed Flow Rate: 620 Nm²/h
Product Flow Rate: 400 Nm²/h
Operating Pressure: 1.5 MPa
Product Hydrogen Purity: 99.999%
1000 Nm²/h Alkaline Electrolyzer for
Hydrogen Production, Deoxygenation,
Dehydration, and Purification via Water Electrolysis
Feed Flow Rate: 1000 Nm²/h
Operating Pressure: 1.6 MPa
Product Hydrogen Purity: 99.999%
TSA pretreatment unit
(can be used as a PSA pretreatment unit to
pretreat impurities such as water,
ammonia, and hydrocarbons).
PDH Hydrogen Tail Gas Purification for
Electronic Grade Ultrapure Hydrogen
Feed Flow Rate: 4000 Nm²/h
Product Flow Rate: 3800 Nm²/h
Operating Pressure: 1.8 MPa
Product Hydrogen Purity: 99.9999%
Coal gas to hydrogen production unit
Feed flow rate: 30 Nm²/h
Product flow rate: 20 Nm²/h
Operating pressure: 1.0 MPa
Product hydrogen purity: 99.99%
TSA+PSA+VPSA Single Impurity Removal Test Project
Raw Material Flow Rate: 600 Nm²/h
Operating Pressure: 2.0 MPa
Product Hydrogen Purity: 99.999%
This test achieves the removal of different
single impurity components from hydrogen
by using different adsorbents and different desorption methods.
